SC9200 96 & 384 全自動移液工作站

SC9200 96 & 384 全自動移液工作站
SC9200 96 & 384 全自動移液工作站

獨一無二的寬量程范圍 領先的高精度移液系統

提供0.5~20 μL、5~200 μL、10~300 μL、50~1250 μL、0.5~12.5 μL、5~125 μL多個量程



高效、快速、精準 微孔板移液一揮而就

多通道移液器已普遍用于提高當今實驗室的通量。然而，大量的手動移液操作仍然需要寶

貴的時間，并可能造成重復性勞損。另外，在樣品量不斷減小的趨勢下，恰當、準確地移

液正在變得越來越困難。

SC9200 延續了其直觀的操作和緊湊的設計，能夠使用 24、96 和 384 通道移液頭，以實

現更高的效率。SC9200 是一款開放設計的緊湊型全自動移液工作站，標配 5 個 SBS 標準

板位，具有高效、便捷、精準的特性，能同時兼容 8/16/24/96/384 通道的液體處理。

X/Z 軸運動，實現全方位操控?？煞胖眠x配件和符合 SBS 標準的孔板；方便自支動化整合，

如整合疊板機和機械臂等。

SC9200 集多種移液功能于一身，僅需單擊運行，即可完成不同類型實驗的切換。可一次

性處理 8/16/24/96/384 通道移液，完成微孔板間快速移液。

Zworks 操作步驟簡潔明了，簡單培訓即可上手操作，可實現無人值守，可自動更換吸頭完

成實驗操作，解放實驗員的雙手，確保實驗技術的穩定性和可重復性。SC9200 同時兼容

遠程操控對一些有特殊要求的實驗環境，儀器可置于通風櫥、超凈臺等，不僅降低了對實

驗干擾，還能確保實驗人員的安全。



為什么要選擇我們的SC9200

什么使這些設備如此智能？

? 靈活的量程范圍 — SC9200 提供多種核心：0.5~20 μL、5~200 μL、10~300 μL、

50~1250 μL、0.5~12.5 μL、5~125 μL 具有出色的準確性和重復性。

? 可更換移液核心 — 多通道，多個可自由更換核心，完成 0.5-1250 μL 體積的移液，一

分鐘即可完成更換，完美匹配您的應用需求。

? 準確、精準 — 精確工程設計， μ 級制造工藝，使 96 個活塞同步移動，每個通道都是

單獨的，以排除任何跨通道影響，通道間一致性提供高質量的分析數據，對每個研究項目

都物有所值。即使操作人員或環境發生變化，SC9200 也能保證實驗的重復性。

? 全自動移液 — 體積精巧且能左右、上下移動，所以無需輔助，就能自動完成轉板（96

轉 96、96 轉 384）能靈活完成 24/96/384 通道的全自動液體處理。

? 體積小巧、節省空間 — 采用超緊湊和輕量化設計，便于在實驗室中移動和置入超凈臺、

通風櫥、安全柜等；對一些有特殊要求的實驗環境，使用無線方式控制儀器，不僅降低了

對實驗干擾，還能確保實驗人員的安全。

? 孔板分液速度的革命 — 12 倍于 8 通道排槍的效率，96 / 384 通道核心可一次性完成

96 / 384 等多種微孔板移液操作。無需輔助，一鍵完成裝卸載吸頭，加分樣，混勻等動作；

同時配備可拆卸的二級平臺以減少實驗室器具操作。

? 精確控制 — ZWorks 其卓越的高自由度調度功能，可以容易地控制移液操作的每個細

節，例如控制體積校準因子、移液速度、吸頭是否需要碰觸微孔板孔壁，以及精確控制移

液頭和吸頭進出耗材的運動。

? 圖形化操作界面 — Pad 控制端，圖形化的操作界面，直觀易學，具有程序存儲、孔板

記憶等功能，確保具有可重復性、可再現性。

? 完美耗材兼容 — 兼容大部分符合 SBS 標準的實驗耗材、樣品管、吸頭盒、微孔板、儲液槽、廢液槽等。

 集多種移液功能于一身，僅需單擊運行，即可完成不同類型實驗的切換。

以下示例闡述 SC9100 相關應用領域：

藥學領域 ：藥物體外代謝 ? 高通量篩選 ? 化合物庫 ? 生物分析 ? 細胞活性、毒性分析。

醫學領域 ：生物與樣本庫 ? 免疫反應 ? 診斷樣本庫 ? 酶聯免疫吸附測定。

生物學領域 ：抗體實驗 ? 細胞組織培養 ? 測序 ? 引物合成。

檢驗檢測領域 ：CDC 疾控中心 ? 食品藥品檢驗 ? 檢驗檢疫中心，以及更多其他領域。

以下示例闡述 SC9200 相關應用案例：

? 孔板間樣品轉移、復制及重組 ? 細胞接種及培養基更換 ? 化合物及試劑添加 ? 384 孔

板樣品轉移 ? 細胞檢測類實驗 ? ELISA 實驗的孔板包被及洗板操作 ? 基于孔板的生化類檢測，等等。

技術	工作原理
PCR 與 qPCR	利用 中析 吸頭輕松地將 PCR/qPCR 試劑移液至 96 孔板中
酶聯免疫吸附試驗	在全部 96 孔中同時快速添加試劑并啟動 / 停止反應
蛋白晶體學	快速地將緩沖液分配至孔板用于懸滴法
Luminex 分析	將緩沖液、抗體和其他溶液持續地添加至 Luminex 板
藥物化合物篩分	將傳感器、生物分子和化合物快速、準確地添加至 96/384 孔板
對樣品制備進行排序	同時分配緩沖液、酶和核酸
對樣品清潔排序	通過 96 通道移液加速沉淀和純化
標準酶分析	將酶、緩沖液和基質準確、精確地移液至孔板
細胞培養設置	數秒內創建復制板
細胞培養 siRNA 處理	輕松、準確地將 siRNAs 移液至培養板
細胞分析	采用準確的試劑，通過對至多 96 個樣品移液分裂細胞
板復制	最多能同時對 384 個樣品進行轉移，只需要幾秒鐘即可完成整板的復制
試劑添加	對于 ELisa、PCR、DNA 的提取等涉及重復分液的實驗進行整板添加



讓你擁有更可靠的實驗結果

20 μL SC9200 96

全新設計的 SC9200 96 & SC9200 384 各個方面都有了全面改進，從而可以為您提供最可

靠的液體處理解決方案。精確度高，且具有磐石般的持續穩定性，保證每次都給您一個可以信

賴的數據結果。

可靠的密封性及牢固性是高重復及無差錯移液的關鍵，SC9200 96 & SC9200 384 采用了先

進的彈性加載系統，裝槍頭時，槍頭會牢牢鎖定在移液頭上，這保證它們永遠不會意外脫落，

即使在實驗中你用槍頭靠壁也是如此。

此外，該系統提供了移液通道完美的密封，以防止不均勻移液或樣品的泄漏。





擺脫常規移液負擔，簡化各種應用中的常規移液

連續稀釋

手動進行系列稀釋需要專注和良好的移液技巧。SC9200 可確保連續稀釋操作的可重復性并避

免錯誤的發生。使用 SC9200 ，可在每次轉移后更換槍頭，以最大限度減少附著在尖端表面

的殘留物。

孔板填充和試劑添加

構建測定板體系通常需要添加多個樣品以及緩沖液或培養基。SC9200 靈活的臺面布局可容納

試管、儲液槽和孔板，從而實現了向測定板的多步驟轉移。

SC9200 96 & 384 的自動化液體處理方案實際上涵蓋了所有的研發應用。結合了先進的移液

技術，能夠一如既往地提供準確、可靠的性能。獨特的開放式設計使其不僅可以單獨使用，也

可在其任一邊連接其他儀器以進行靈活整合。

高質量設備與服務 基本技術規格 聯系我們，獲取更多技術信息。

儀器                    300μL 的 SC9200                   1250μL 的 SC9200

通道                    24 & 96 & 384 通道                 24 & 96 & 384 通道

體積增量                0.01 μL                            0.01 μL

孔板位置                5                                  5

移液技術                氣體活塞式                         氣體活塞式

電源要求                100-240VAC，50-60Hz                100-240VAC，50-60Hz

控制器                  LCD彩色觸摸屏                      LCD彩色觸摸屏

最大功率                180W                               180W

工作溫度                5-40℃                             5-40℃

尺寸 ( 長 x 寬 x 高 )   5位：75cmx25cmx46cm               5位：75cmx25cmx54cm



測量誤差

量程范圍                通道               準確度            精密度

0.5~20 μL              96 通道            ± 1.5 %          ≤ 1.0 %

5~200 μL               96 通道            ± 1.2 %          ≤ 0.8 %

50~1000 μL             96 通道            ± 1.8 %          ≤ 0.8 %

根據公司內部的標準作業程序（SOP）對設備進行檢查。

環境條件：測試地點：QA 實驗室；環境溫度：15℃ ~24℃；空氣相對濕度 55%~75% 不冷凝；氣壓：860hPa~1060hPa；實驗液體：20℃蒸餾水；采用中析超低吸附吸頭；采用正向移液；每次測試更換吸頭；

訂購信息 訪問我們網站，查看所有可用的配件和耗材。

描述                                       貨號

SC9200 96 移液工作站，0.5~300 μL          S3730

SC9200 96 移液工作站，0.5~1250 μL         S3740

SC9200 384 移液工作站，0.5~125 μL         S3810

1 年度服務計劃                            SF0100

2 年度服務計劃                            SF0200

5 年度服務計劃                            SF0500



描述                                        貨號

96 通道移液頭，0.5~20 μL                  SH0610

96 通道移液頭，5~200 μL                   SH0630

96 通道移液頭，10~300 μL                  SH0640

96 通道移液頭，50~1250 μL                 SH0660

384 通道移液頭，0.5~12.5 μL               SH0700

384 通道移液頭，5~125 μL                  SH0720





中析一次性吸頭

描述               包裝                     預滅菌    濾芯 預滅菌   低吸附 預滅菌    濾芯 低吸附 預滅菌

10μL 盒裝吸頭    96 支 / 盒，                T2142      T2152           T2162           T2172

10 盒 / 中盒，50 盒 / 箱

200μL 盒裝吸頭   96 支 / 盒，                T2342      T2352          T2362            T2372

10 盒 / 中盒，50 盒 / 箱

1000μL 盒裝吸頭  96 支 / 盒，                T2442      T2452           T2462          T2472

10 盒 / 中盒，50 盒 / 箱

1250μL 盒裝吸頭  96 支 / 盒，                T2542      T2552           T2562           T2572

10 盒 / 中盒，50 盒 / 箱





可重復使用的標準型聚丙烯儲液槽

描述                        包裝                             貨號

平底儲液槽（190mL）       5 塊 / 袋，50 塊 / 箱            D0160

8 道儲液槽（22mL）        5 塊 / 袋，50 塊 / 箱            D2140

12 道儲液槽（15mL）       5 塊 / 袋，50 塊 / 箱            D3130

96 道儲液槽（195mL）      5 塊 / 袋，50 塊 / 箱            D6170

384 道儲液槽（185mL）     5 塊 / 袋，50 塊 / 箱            D7150







中析

蘇州中析儀器有限公司

：

郵箱：





中析對于產品的優化升級始終鍥而不舍，

如產品參數發生變化，可通過官網了解最新信息。

SC9200 96 & 384 fully automatic pipette workstation

Unique wide range of leading high precision pipette systems

Provides 0.5~20 μL, 5~200 μL, 10~300 μL, 50~1250 μL, 0.5~12.5 μL, 5~125 μL on multiple scales





High efficiency, fast, accurate microporous plate pipette with a wave

Multi-channel pipettes have been commonly used to improve the flux in today's laboratories.However, numerous manual pipette operations still require a treasure

Your time, and can cause repetitive strain.In addition, under the trend of decreasing sample size

Liquid is getting more difficult.

The SC9200 continues its intuitive manipulation and compact design, capable of using the 24,96, and 384-channel pipette heads for solid use

It is now much more efficient.The SC9200 is an open-designed compact, fully automatic hydropipette station, standard standard with five SBS standards

Plate position, efficient, convenient, accurate, and simultaneously compatible with liquid treatment in 8 / 16 / 24 / 96 / 384 channels.

X/Z-axis motion for all-round control.Options and SBS compliant orifice plates; easy self-supporting integration,

Such as integrated plate folding machine and mechanical arm, etc.

SC9200 integrates a variety of pipette functions, and just click Run to switch between different types of experiments.But once

Sexual treatment in 8 / 16 / 24 / 96 / 384 channel to complete rapid pipettion between microplates.

Zworks operation steps are simple and clear, simple training can be started operation, can achieve unattended, can automatically replace the suction head

Into the experimental operation, to liberate the hands of the experimenter, to ensure the stability and repeatability of the experimental technology.The SC9200 is simultaneously compatible

Remote control for some special requirements of the experimental environment, the instrument can be placed in the ventilation closet, super clean table, etc., not only reduces the reality

Inspection of interference, can also ensure the safety of the experimenters.



Why choose our SC9200

What makes these devices so smart?

Flexible scale range — SC9200 offers multiple cores: 0.5~20 μL, 5~200 μL, 10~300 μL,

50~1250 μL, 0.5~12.5 μL, 5~125 μL has excellent accuracy and reproducibility.

Replacement pipette core-multichannel, multiple freely replaceable cores, complete a 0.5-1250 μL volume of pipette, one

Rethe replacement in ten minutes to match your application needs.

Accurate, accurate-accurate engineering design, grade μ manufacturing process, make 96 pistons move synchronously, each channel is

Separately, to exclude any cross-channel impact, inter-channel consistency provides high-quality analytical data for each study project

It's worth money.SC9200 guarantees reproducibility of experiments even if the operator or environment changes.

Automatic hydropipette- -exquisite volume and can move up and down, so you can automatically complete the transfer plate without assistance (96

Turn 96,96 turn 384) can flexibly complete the fully automatic liquid treatment in the 24 / 96 / 384 channel.

Small, space saving-ultra-compact and lightweight design for easy movement and placement in the lab

Ventilation cabinet, safety cabinet, etc.; for some special requirements, the use of wireless control instruments, not only reduced

Interference with the experiment can also ensure the safety of the experimenter.

The revolution of the liquid separation speed of the hole plate- -12 times the efficiency of the 8-channel gun discharge, and the 96 / 384-channel core can be completed at one time

96 / 384 Various microplates.Without assistance, one key to complete the loading and unloading suction head, additional samples, mixing and other actions;

Provide a removable secondary platform to reduce laboratory appliance operation.

Precise Control-ZWorks its excellent high degree of freedom scheduling function can easily control every fine of pipette operation

Sections, such as control volume calibration factor, pipette velocity, whether the suction head needs to touch the microplate wall, and precise control shift

Movement of liquid heads and suction heads in and out of consumables.

Graphical operation interface-Pad control end, graphical operation interface, intuitive and easy to learn, with program storage, hole plate

Memory and other functions, to ensure that is reproducible, reproducibility.

Perfect consumables compatibility-compatible with most experimental consumables, sample tube, suction head box, microwell plate, liquid storage tank, waste liquid tank, etc., that meet SBS standards.



Set a variety of pipette functions in one, just click Run to switch between different types of experiments.

The following examples illustrate the SC9100-related application areas:

Field of pharmacy: Cell activity and analysis of bioanalysis and toxicity analysis.

Medical field: enzyme-linked immunosorbent determination of sample library.

Biology: primer synthesis for tissue culture of antibody experiments.

Inspection and testing field: CDC Center for Disease Control and Prevention Food and Drug Inspection, Inspection and Quarantine Center, and more and other fields.

The following examples illustrate the SC9200-related application cases:

Between-plate sample transfer, replication and recombinant cell inoculation and medium replacement compounds and reagents added to 384 wells

Plate sample transfer cell assay experiment ELISA experiment of pore plate packaging and plate washing operation based on biochemical pore plate detection, etc.

Technology                          Working principle

PCR, qPCR                           PCR/qPCR reagent was easily pived into 96-well plates using a medium suction head

Enzyme-linked immunosorbent assay    Reagent were quickly added and initiated / stopped in all 96 wells

Protein Crystallography             Apply the buffer to the well plate quickly for droplet suspension

Luminex analysis                    Buffers, antibodies, and other solutions were continuously added to the Luminex plates

Drug compound screening points      Sensors, biomolecules, and compounds were added quickly and accurately to 96 / 384-well plates

Sample preparation was sorted       Buffers, enzymes, and nucleic acids were also assigned

Clean clean samples                  Precipitation and purification were accelerated by a 96-channel pipette

Standard enzyme analysis            The enzyme, buffer and substrate were accurately and accurately to the pore plate

Cell culture settings               Create a copy board in seconds

Cells were cultured with            siRNAs was liquid easily and accurately transferred siRNA treatmentThe                 to the culture plate

Cell analysis                      Accurate reagents were used by dividing cells with up to 96 samples

Plate replication                  Up to 384 samples can be transferred simultaneously in only a few seconds to complete the entire plate

The reagent was added              Whole plate addition was performed for experiments involving repeated fluids such as extraction of ELisa, PCR, DNA



Let you have a more reliable experimental results

20 μL SC9200 96

The new design features comprehensive improvements in all aspects of the SC9200 96 & SC9200 384 to give you the most available

A reliable liquid treatment solution.High accuracy, and has a rock-like continuous stability, to ensure to give you a letter every time

Lai's data results.

Reliable sealing and firmness are the key to high repetition and error-free fluid removal, and SC9200 96 & SC9200 384 is adopted first

The elastic loading system locks the head to the pipette, ensuring that they will never accidentally fall off,

Even in the experiment you use the gun head against the wall.

In addition, the system provides a perfect seal of the pipette channel to prevent uneven pipettes or leakage of samples.



Get rid of the conventional pipette burden and simplify the conventional pipette in various applications

Continuous dilution

Manual serial dilution requires concentration and good pipette skills.SC9200 ensures reproducible and avoidance of serial dilution operations

Error-free occurrence.Using the SC9200, replaces the gun head after each transfer to minimize attachment to the tip surface

Residues.

Holplate filling and reagent addition

Building the determination plate system usually requires the addition of multiple samples as well as buffer or medium.SC9200's flexible countertop layout accommoaccommodate

The tube, reservoir and orifice plate achieved multi-step transfer to the measuring plate.



SC9200 96 & 384's automated liquid treatment scheme actually covers all R & D applications.Advanced pipettes were combined

Technology delivers deliver accurate and reliable performance.The unique open-plan design makes it available not only alone, but also

Other instruments can be connected on either side for flexible integration.



High quality consumables and services (part

Contact us for more technical information.



Instrument                 The SC9200 of 300 μL        The SC9200 of 1250 μL

Channel                    24 & 96 & 384                24 & 96 & 384

Volume increment           0.01 μL                      0.01 μL

Holplate position          5                            5

Pipette technology         gas piston type              gas piston type

Power supply requirement  100-240VAC,50-60Hz            100-240VAC,50-60Hz

Controller                LCD Color touch Screen        LCD color touch screen

Maximum power of          180W                          180W

Operating temperature     5-40℃                        5-40℃

Dimensions                5 bit: 75cmx25cmx46cm         5 bit: 75cmx25cmx54cm

(long x wide x high)





Measurement error

Range-range           channel            accuracy           precision

0.5~20 μL             96 channel         ± 1.5%            ≤ 1.0%

5~200 μL             96 channel          ± 1.2%           ≤ 0.8%

50~1000 μL           96 channel          ± 1.8%           ≤ 0.8%





Check the equipment as per the company's internal standard operating procedures (SOP).

Environmental conditions: test site: QA laboratory; ambient temperature: 15℃ ~24℃; air relative humidity 55%~75% 75% no condensate; air pressure: 860hPa~1060hPa; experimental liquid: 20℃ distilled water; intermediate analysis; forward pipette; suction head replaced for each test;



Order information visit our website to view all available accessories and consumables.



Describe                                       the shipment number

SC9200 96 Shipete Workstation,0.5~300 μL               S3730

SC9200 96 Shipete Workstation,0.5 ~ 1,250μL            S3740

SC9200 384 Shipete Workstation,0.5~125 μL              S3810

1 Annual Service Plan                                  SF0100

2 Annual Service Plan                                  SF0200

5 Annual Service Plan                                  SF0500



Describe                                        the cargo number

96 Channel pipette head, 0.5~20 μL                   SH0610

96 Channel pipette head, 5~200 μL                    SH0630

96 Channel pipette head, 10~300 μL                   SH0640

96 Channel pipette head, 50 ~ 1,250 μL               SH0660

384 Channel pipette head, 0.5~12.5 μL                SH0700

384 Channel pipette head, 5~125 μL                   SH0720



One-time suction head

Describe       the packaging      pre-sterilization   filter       low adsorption     low adsorption

                                           pre-sterilization  pre-sterilization    filter pre-sterilization

10 μL box with  96 pieces / box,     T2142        T2152          T2162           T2172

suction head     10 boxes / medium

boxes, 50 boxes / boxes

200 μL box with  96 pieces / box,    T2342        T2352          T2362           T2372

suction head      10 boxes / medium

 boxes, 50 boxes / boxes

1000 μL box with  96 pieces / box,   T2442        T2452          T2462           T2472

 suction head      10 boxes / medium

 boxes, 50 boxes / boxes

1250 μL box with  96 pieces / box,   T2542        T2552          T2562           T2572

suction head       10 boxes / medium

 boxes, 50 boxes / boxes







Reusable standard-type polypropylene storage tank

Description                        the packaging                   shipping number

Flat bottom storage tank (190mL)   5 pieces / bag, 50 pieces / box      D0160

Eight storage tanks (22mL)         5 blocks / bag, 50 blocks / box      D2140

12 Storage tanks (15mL)            5 blocks / bag, 50 blocks / box      D3130

96 Storage tanks (195mL)           5 blocks / bag, 50 blocks / box      D6170

384 Storage tank (185mL)           5 blocks / bag, 50 blocks / case     D7150









Zhongxi

Suzhou Zhongxi Analysis Instrument Co., Ltd

Tel.:

Email:

本頁產品地址：http://www.okbaiwei.com/sell/show-7803287.html
